Dante 70 Watt Amplifier
This product is designed as a two-channel amplifier using class D amplifier technology. It can be used for powering low impedance (4Ω/8Ω) stereo systems with a maximum power of 2x 15 Watts or 1x 30 Watts (Mono). It features Dante® 2-channel digital inputs and outputs, and 2-channel balanced or unbalanced analog inputs and outputs. Analog input supports microphone input as well as 48V phantom power for condenser microphones. This product has built-in audio DSP for gain, mixing, matrixing, equalizer, volume, and delay control. This amplifier can be controlled via RS-232, TCP/IP, and Web GUI. This product is suitable for a vast range of AV installations.
A${{shopModel.rebate>0?shopModel.discountPriceStr:shopModel.formattedAmount}}
A$ {{shopModel.formattedAmount}}
Like
{{item.name}}
Quantity：
Estimated Delivery Date: May 21-May 26
Frequently Asked Questions
How can I contact customer service?
Do you ship overseas?
How long will it take to get my order?
Specifications
{{item.name}}
{{item.value}}
Features
▪ Advanced 70W Class-D audio amplifier with Dante integration
2x 35W@4/8ohm,
- 1x 70W@4/8ohm
- Dante® 2x2 and AES67 audio input/output supported
- Balanced/unbalanced analog input and output for cascading connection
- Dante® 2CH digital audio, balanced or unbalanced line level analog and AMP outputs
- Supports microphone input with 48V phantom power
- Audio DSP processing includes gain, ducking, mixing, matrixing, equalizer, volume and delay control
- Audio output supports 8 band PEQ adjustment (with +15dB/-15dB gain), and a maximum of 50ms delay setting
- Auto standby mode (0~100 minutes can be set) with signal sensing
- Local 5-12V input trigger for disabling amplifier output
- Integrated web page function, which can control the local machine and query the working status of the product through the web page
- Supports network control function, slave devices in the same network segment can be controlled through the set host
- Dante audio support: 44.1kHz, 48kHz, 88.2kHz, and 96kHz sampling rates @ 16/24bit
- Dante audio delay supports settings of 2, 3, 4, 5 or 10ms
- Flexible control via front panel buttons, RS-232, TCP/IP and Web GUI
- Power via PoE or local DC power supply (Amplifier power limited when using PE)
Package Contents
- 1x 2x35W Class D Audio Amplifier
- 2x 6pin-3.5mm Phoenix Connector (male)
- 1x 5pin-3.5mm Phoenix Connector (male)
- 1x 4pin-5.08mm Phoenix Connector (male)
- 2x Mounting Ear
▪ 4x Machine Screw - 1x 24V/2A Multinational Power Supply (1.5 meters)
- 1x User Manual
